Description

Class: RINA C ? HULL, Pontoon, Special Navigation; ICE CLASS IC, STRENGTHBOTTOM, INWATERSURVEY
Main Dimensions:
Length: 89.25 m
Beam: 16.5 m
Depth: 4.5 m
Draft: 0.8 – 3.0 m
Capacity: approx. 3,100 MT
Deck Strength: 15 MT/m²
Additional Features:
Laden Draft: 3 m
DWT: 3100 MT
Ramp access: 12m beam at fore and stern
RINA Class: HULL, Pontoon, Special navigation
Ballast pumps: 2 x 400 m³/hr
RORO ramp access arrangement at fore and stern
Suitable for offshore renewables logistics, heavy cargo transportation and marine project support operations
LOA 89.25 m
Beam 16.5 m
Draft 3.2 m

Built in year 2019
Design is : Damen SPo 8916
Class : Registro Italiano Navale
Flag : Palau
Gross Tonnage of 1,717 and Nett Tonnage of 515

Deadweight : 3,070 metric tonnes
Free Deck area about 1,150m² with a deck strength of 15 metric tonnes per square meter
Ice classed 1C

Engines : Unknown Builder

1 Deck

Specifications
