Description

LOA 85 m
Beam 20 m
Draft 5 m

Built in year 2010
Class : Bureau Veritas
Flag : Marshall Islands
Gross Tonnage of 3,891 and Nett Tonnage of 1,167

Dynamic Positioning of class : DP 1
Free Deck area about 800m² with a deck strength of 10 metric tonnes per square meter
Heli Deck installed
8-Point installed
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 20 tons
Deadweight : 2,340 metric tonnes

Total 126 berths

Speed : 12 knots
Engines : 2 x Caterpillar / Caterpillar Inc 3516B, 3,788 kw, 1,600 rpm, Propellers 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
Auxiliaries Engines : 2 Caterpillar 856 kw + 1 Caterpillar 534 kw, Bowthruster + Sternthruster (2 Bow Tunnel thruster + 1 Stern Tunnel thruster)

Specifications

Engine(s)

2 x 3,788 kw, 1,600 rpm, Caterpillar / Caterpillar Inc 3516B,
Propellers: 1 Controllable Pitch (Port Side) + 1 Controllable Pitch (Starboard)
