| GRS.OFFSHORE RENEWABLES | |
| Stadthausbruecke 7, Hamburg, Deutschland, 20355, Germany | |
| Contact: | S&P Broker |
| Telephone: | Reveal Telephone Number |
| Telephone: | Reveal Telephone Number |
| Mobile: | Reveal Mobile Phone Number |
| View All GRS.OFFSHORE RENEWABLES Listings | |
Description
LOA 66 m
Beam 20 m
Draft 4,3 m
Built in year 2013
Class : American Bureau of Shipping
Flag : Vanuatu
Gross Tonnage of 2.637 and Nett Tonnage of 791
Dynamic Positioning of class : DP 2
4-Point installed
Fire Fighting System of type FiFi 1 installed
1 Crane / Gear installed with a max lifting capacity of 40 tons
Deadweight : 1.375 metric tonnes
Capable of supplies of 500m³ Fuel Oils and 600m³ FW
Total passenger capacity 60
Speed : 11 knots
Engines : 4 x Caterpillar / Caterpillar Inc 3512C, 7.060 kw, 1.800 rpm, Propellers 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard)
Auxiliaries Engines : Bowthruster + No Sternthruster (2 Bow Tunnel thruster)
Specifications
| Builder: | GUANGDONG YUEXIN OCEAN ENG |
| Constructed: | 2013 |
| Guests: | 60 |
| No. of engines: | 4 |
| Engine power: | 9470 |
| Cruising Speed: | 11. knots |
| Length over all: | 66m |
| Beam: | 20m |
| Maximum draft: | 4.3m |
| Water capacity: | 600.0 Cubic Metres |
Engine(s)
4 x 7.060 kw, 1.800 rpm, Caterpillar / Caterpillar Inc 3512C,
Propellers: 1 Azimuth Elec. Dr. (Port Side) + 1 Azimuth Elec. Dr. (Starboard)
Certification
REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified
MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network
Disclaimer
GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.
Location Map
Note: Indicated location is approximate general area only.
