Telescopic Marine Crane particulars:
GRU Marina 260 to.
Single pull 40 To.
Type VVMT 260.000 ST3/R2/24
No:1027717—19 24.02.1999
RINA 98/NA/5987/CO
Hydr. Tank Capacity 1500 Ltr.
Rotational Torque 181 kNm
Rotational Angle 360 Continu
Weight of crane 40 Tons
Crane is stored dismantled in Germany
Crane was lately 02/2023 removed from vessel therefore is presently incomplete. Crane hydraulic power pack is still on board (two hydraulic pumps, one oil tank). Can be dismantled on request.
Crane slewing bearing is out of order due wear, renewal required. Crane pedestal is available (presently stored on shore in the Netherlands). Last major overhaul of crane was in 2019 in Poland incl. rebuilding of all hydraulic cylinders at specialized workshop. - Reports can be provided upon request -
Crane wire changed during overhaul in 2019 as well. Last overhaul (crane cabin upgrade + renew of hydraulic hoses) was done 2022 – small report can be provided upon request.
Rotary Joint overhauled in 2022

Crane and Foundation located EU Continent where also inspectable.

Built in year 1999

1 Crane / Gear installed with a max lifting capacity of 40 tons
